In the plastic processing industry, single screw plastic extruder machine is one of the key equipment, which is used to process various plastic resins into uniform pellets to meet the needs of downstream production. With the continuous expansion of the application field of plastic products, the market demand for single screw plastic extruder machines of different types and outputs is becoming increasingly diversified. This article will deeply explore the characteristics of Single Screw Plastic Extruder Machines with different outputs, applicable scenarios, and how to make reasonable choices based on actual production needs.

1. Working principle of single screw plastic extruder machine

The single screw plastic granulating extruder is mainly composed of a feeding system, an extrusion system, a die and a die, a pelletizing system, and a control system. The plastic raw material enters from the feed port and is transported, compacted, melted, mixed, and plasticized in the barrel by the rotation of the screw. As the screw continues to rotate, the molten plastic passes through the die and the die to form strips of a specific shape, which are then cut into uniform pellets by the pelletizing system.

2. Characteristics of single screw plastic extruder machines with different outputs

Low output (100kg/h to 300kg/h)

This type of machine is usually small in size, relatively simple in structure, easy to operate, and suitable for small-scale production environments such as small plastic processing plants or laboratories. Its power consumption is low and the equipment cost is relatively economical.

For example, some small companies specializing in the production of customized plastic products can flexibly adjust the production schedule and effectively control costs by using low-output single screw plastic granulation extruders for small batch orders from specific customers. At the same time, it also helps companies conduct small-scale trials in the new product development stage to quickly verify the feasibility of different formulas and processes.

Medium output (300kg/h to 600kg/h)

The single screw plastic granulation extruder with medium output has been further improved in performance and stability. It can meet the daily production needs of medium-sized plastic processing companies and is suitable for granulation processing of a variety of common plastic materials, such as PE, PP, etc.

This equipment is more optimized in the quality and precision of parts and components, which can ensure stable operation for a long time and reduce downtime. Moreover, the control system is more intelligent, which can achieve precise control of key parameters such as temperature, pressure, and screw speed, thereby improving the consistency of granulation quality.

High output (600kg/h to 800kg/h)

High-output Single Screw Plastic Extruder Machines are the main equipment of large-scale plastic processing companies. They have a powerful power system and can efficiently process large amounts of plastic raw materials to meet the needs of large-scale production.

In order to meet the production requirements of high output, this type of machine is designed with more advanced cooling systems and higher mechanical strength. For example, its screw and barrel are usually made of special alloy materials and are precision machined to improve wear resistance and thermal conductivity. At the same time, it is equipped with an efficient pelletizing system, which can ensure the shape and size accuracy of the particles at high speeds, ensuring that the product quality meets high standards.

3. How to choose a suitable output machine

According to production scale and order requirements

First, it is necessary to clarify the production scale of the enterprise and the expected annual output. If it is a small family workshop or a newly started plastic processing enterprise, the initial order volume is small and unstable, then choosing a low-output single-screw plastic granulation extruder is a more appropriate choice. This can avoid wasting resources by leaving the equipment idle, while reducing the initial investment cost.

For medium-sized enterprises with a certain production base and a stable source of orders, medium-volume machines can better balance production efficiency and equipment costs. Based on historical order data and future business development forecasts, equipment with a production range of 300kg/h to 600kg/h can be reasonably selected to meet daily production needs and have certain expansion capabilities.

Large plastic processing companies or companies participating in large-scale project bidding need to consider high-volume Single Screw Plastic Extruder Machines. For example, companies that provide a large number of plastic pipes and pipe fittings raw materials to the construction industry, or companies that supply plastic parts granules to the automotive manufacturing industry, high-volume equipment can ensure that large-scale orders are completed within the specified time and improve the market competitiveness of the company.

Consider the characteristics of plastic materials

Different plastic materials have different requirements for equipment during processing. For example, when processing PVC materials, because they are more sensitive to temperature and shear rate during the melting process, it is necessary to select medium-to-high-volume machines that can accurately control temperature and screw speed, and the mixing performance of the equipment should be good to ensure the quality uniformity of PVC granules.

For plastic materials with good fluidity such as ABS, the requirements for equipment are relatively lower. However, if the company has the need to produce ABS particles on a large scale, a high-yield single-screw plastic granulation extruder is still a better choice to achieve efficient and stable production.

Combined with the company's financial strength and long-term development plan

The company's financial situation is one of the important factors affecting equipment selection. Low-yield machines are relatively cheap and suitable for small companies with limited funds. However, the service life and subsequent maintenance costs of the equipment should also be considered to avoid frequent replacement of equipment and increase the total cost.

If the company has a long-term development plan and expects that the production scale will gradually expand in the future, then when choosing equipment, it can appropriately consider medium and high-yield machines with certain upgrade potential, or when purchasing low-yield machines, understand whether they have the possibility of subsequent upgrades, such as whether the output can be increased by replacing screws, motors and other parts to meet the company's development needs and avoid repeated investment.

In short, Single Screw Plastic Extruder Machines have different characteristics and applicable scenarios. When choosing, enterprises need to comprehensively consider production scale, order demand, plastic material characteristics, their own financial strength and long-term development plan and other factors to make reasonable decisions, so as to achieve efficient plastic granulation production and improve the economic benefits and market competitiveness of enterprises. At the same time, it is also very important to maintain good communication with equipment suppliers. We can provide professional advice and customized solutions according to the specific needs of enterprises to ensure that the selected equipment can meet the production requirements of enterprises to the greatest extent.
